T10 288V/37Ah (10.65kWh)
T14 384V/37Ah (14.20kWh)
T17 480V/37Ah (17.76kWh)
T21 576V/37Ah (21.30kWh)
Performance & Specification
Features and advantages
Maximum safety performance with LFP technologies
Built-in aluminum heat sink, optional heating solutions
Compact design with flexible size options
IP65 protection for indoor and outdoor use
Compatible with leading inverter brands
Black start function available, quick installation
Specification
|
Model
|
Tower T10
|
Tower T14
|
Tower T17
|
Tower T21
|
|
Usable Energy
|
10.65KWh
|
14.20KWh
|
17.76KWh
|
21.31KWh
|
|
Nominal Capacity
|
37Ah
|
37Ah
|
37Ah
|
37Ah
|
|
Nominal Voltage
|
288V
|
384V
|
480V
|
576V
|
|
Maximun Continuous Discharge Power
|
10KW
|
14KW
|
17KW
|
21KW
|
|
Maximun Continuous charge Power
|
10KW
|
14KW
|
17KW
|
21KW
|
|
Net Weight
|
149Kg
|
192Kg
|
235Kg
|
278Kg
|
|
Dimension[W*D*H]
|
800*510*510mm
|
988*510*510mm
|
1175*510*510mm
|
1360*510*510mm
|
|
Protection Level
|
IP65
|
IP65
|
IP65
|
IP65
|
|
Catendar Life [1]
|
6000 Cycles
|
6000 Cycles
|
6000 Cycles
|
6000 Cycles
|
|
Charging Temperature Range
|
0～45℃
|
0～45℃
|
0～45℃
|
0～45℃
|
|
Discharging Temperature Range
|
-10～45℃
|
-10～45℃
|
-10～45℃
|
-10～45℃
|
|
Intemal Battery Module
|
T9637
|
T9637
|
T9637
|
T9637
|
|
Module Connection
|
series
|
series
|
series
|
series
|
|
Module Number
|
3
|
4
|
5
|
6
|
|
Commnication
|
CAN
|
CAN
|
CAN
|
CAN
|
|
Warranty
|
10 Years
|
10 Years
|
10 Years
|
10 Years
|
[1] Test conditions:0.2C Charging/Discharging,@25℃,80% Dod
